Selenia User Guide
Appendix A—System Specifications
MAN-03270 Revision 003 113
Appendix A
Appendix A System Specifications
A.1 Dimensional Information
A.1.1 Tubestand (Gantry with C-arm)
Figure 81: Tubestand Dimensions
A.
Height with C-arm Travel
213.0 cm (84.07 inches) ±1.0 cm (0.4 inches) at highest C-arm
travel
B.
Height
190.0 cm (74.8 inches)
C.
Width
65.0 cm (25.6 inches) ±1.0 cm (0.4 inches) (C-arm at 0° position)
D
Depth
110.0 cm (43.3 inches)±1.0 cm (0.4 inches)
Weight
300 kg (661 lb) ±20 kg with Image Receptor
A.1.2 Acquisition Workstation
Figure 82: Acquisition Workstation Dimensions
A
Height
189.5 cm (74.6 inches) (maximum)
B
Width
107 cm (42.1 inches)
C
Depth
76 cm (30.0 inches)
D
Swivel Arm Radius
60.5 cm (23.81 inches)
Weight
120 kg (264.5 lb) (maximum)
