Selenia User Guide
Chapter 6—The User Interface
MAN-03270 Revision 003 79
6.2.8.2.10 Calibrations
When Calibration is needed, the Select a Patient screen remains in Standby and the
Calibration Needed Alarm message appears in the System Message box.
When you turn on the system, a message appears if the system needs any calibration. You
cannot acquire the patient exposures until you perform the required calibration. All the
review, resend, and administrative functions continue to work.
Caution:
It is important to follow the directions on the screen when
you calibrate a system.
Note
Clean the detector and acrylic block before you perform a
Calibration.
If you are in the Calibration Mode screen by accident, select the End Calibration button. If
you started the Calibration, but you did not accept images, you can reject the Image and
exit the Calibration.
Note
When you accept one image, do not end the calibration
before you acquire, view, and accept all the images.
6.2.8.2.11 Test Patterns
Note
See DICOM Printer Quality Control in the Selenia Quality
Control Manual for more information about the SMPTE test
pattern.
1. Select Admin>Test Patterns.
2. From the Output area of the screen:
• Select the Output Device from the drop-down list.
• Select the Film Size from the drop-down list.
• Uncheck the Print True Size check box.
3. Select the Test Pattern from the Pattern drop-down list.
4. Select from the options at the bottom of the screen:
• To view the test pattern Full Screen, select the Preview button. To return to the
dialog box, click any area on the Full Screen.
• To send the Test Pattern to the selected output, select the Send button.
• To remove any files from previous "sends" before you send the current images,
select the Clean Up button.
• To exit the Test Pattern option, select Close.
