3-20
dummyheaddummyhead
MAINTENANCE
Make sure that the pins are staked properly by
measuring the diameter of the staked area using a slide
caliper [1].
After staking, check the staked area of the master link
for cracks.
If there is any cracking, replace the master link, O-rings
and plate.
DRIVE CHAIN SLIDER
Check the drive chain slider for wear or damage.
The drive chain slider must be replaced if it is worn to
the wear indicator [1] (page 18-16).
DIAMETER OF THE STAKED AREA:
DID: 5.40 – 5.60 mm (0.213 – 0.220 in)
RK: 5.25 – 5.65 mm (0.207 – 0.222 in)
[1]
[1]
[1]

Honda NC700 2012 Specifications

General

Engine Type	670cc liquid-cooled parallel-twin
Bore x Stroke	73.0mm x 80.0mm
Compression Ratio	10.7:1
Front Brake	Single 320mm disc with two-piston caliper
Rear Brake	Single 240mm disc with single-piston caliper
Fuel Capacity	3.7 gallons
Fuel System	PGM-FI
Transmission	6-speed
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock
Front Tire	120/70-17
Rear Tire	160/60-17
Wheelbase	60.6 inches
Curb Weight	472 pounds
