11-9
dummyheaddummyhead
CLUTCH/GEARSHIFT LINKAGE (NC700X/XA/S/SA)
Remove the clutch outer guide [1].
INSPECTION
CLUTCH LIFTER BEARING
Turn the inner race of the clutch lifter bearing [1] with
your finger.
The bearing should turn smoothly and quietly.
Also check that the outer race of the bearing fits tightly
in the pressure plate.
Replace the clutch lifter bearing if the inner race does
not turn smoothly, quietly, or if the outer race fits loosely
in the lifter plate.
CLUTCH SPRING
Replace the clutch
springs as a set.
Measure the clutch spring free length.
CLUTCH CENTER
Check the grooves [1] of the clutch center for damage
or wear caused by the clutch plates.
Replace it if necessary.
[1]
[1]
SERVICE LIMIT: 41.7 mm (1.64 in)
[1]

Honda NC700 2012 Specifications

General

Engine Type	670cc liquid-cooled parallel-twin
Bore x Stroke	73.0mm x 80.0mm
Compression Ratio	10.7:1
Front Brake	Single 320mm disc with two-piston caliper
Rear Brake	Single 240mm disc with single-piston caliper
Fuel Capacity	3.7 gallons
Fuel System	PGM-FI
Transmission	6-speed
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock
Front Tire	120/70-17
Rear Tire	160/60-17
Wheelbase	60.6 inches
Curb Weight	472 pounds
