6-6
dummyheaddummyhead
ELECTRIC STARTER
7. Starter Relay Switch Continuity Inspection
Remove and check the operation of the starter relay switch (page 6-11).
Is there continuity?
YES – Loose or poor contact starter relay switch connector
NO – Faulty starter relay switch
Starter motor does not turn (NC700XD/SD)
1. Fuse Inspection
Check for blown main fuse (30 A), ENG STOP fuse (7.5 A) and FI fuse (15 A).
Are the fuses in good condition?
YES – GO TO STEP 2.
NO – Replace the blown fuse.
2. Battery Inspection
Make sure the battery is fully charged and in good condition (page 21-6).
Is the battery in good condition?
YES – GO TO STEP 3.
NO – Charge or replace the battery.
3. Starter Relay Switch Operation Inspection
Check the starter relay switch operation (page 6-10).
Does the starter relay switch click?
YES – GO TO STEP 4.
NO – GO TO STEP 5.
4. Starter Motor Inspection
Turn the ignition switch OFF.
Apply battery voltage directly to the starter motor and check the operation.
Does the starter motor turn?
YES – • Poorly contacted battery positive cable or starter motor cable
• Faulty starter relay switch
NO – Faulty starter motor (page 6-8)
5. Relay Coil Input Line Inspection
Check the relay coil input line of the starter relay switch (page 6-10).
Is the input line normal?
YES – GO TO STEP 6.
NO – • Faulty ignition switch (page 22-24)
• Faulty starter switch (page 22-25)
• Faulty engine stop switch (page 22-25)
• Loose or poor connected connector
• Open circuit in the wire harness
6. Relay Coil Ground Line Inspection
Check the relay coil ground line of the starter relay switch (page 6-11).
Is the ground line normal?
YES – GO TO STEP 7.
NO – GO TO STEP 8.
7. Starter Relay Switch Continuity Inspection
Check the starter relay switch (page 6-11).
Is there continuity?
YES – Loose or poor contact starter relay switch connector
NO – Faulty starter relay switch
