Honda NC700 2012 User Manual

3-27
dummyheaddummyhead
MAINTENANCE
Major adjustment is made with the lower adjusting nut
[1] at the clutch lifter arm.
Loosen the lock nut [2] and turn the adjusting nut to
adjust the freeplay.
Tighten the lock nut while holding the adjusting nut.
If proper freeplay cannot be obtained, or the clutch slips
during test ride, disassemble and inspect the clutch
(page 11-7).
SIDESTAND
INSPECTION
Support the motorcycle using a safety stand or hoist.
Check the sidestand spring [1] for damage or loss of
tension.
Check the sidestand [2] assembly for freedom of
movement and lubricate the sidestand pivot if
necessary.
Check the sidestand ignition cut-off system:
– Sit astride the motorcycle and raise the sidestand.
– Start the engine with the transmission in neutral,
then, with the clutch lever fully squeezed, shift the
transmission into gear.
– Move the sidestand full down.
– The engine should stop as the sidestand is lowered.
If there is a problem with the system, check the
sidestand switch (page 22-28).
REMOVAL/INSTALLATION
Support the motorcycle upright on a level surface.
Remove the sidestand switch bolt [1] and sidestand
switch [2].
[1]
[2]
[1]
[2]
[1] [2]

Honda NC700 2012 Specifications

General

Engine Type	670cc liquid-cooled parallel-twin
Bore x Stroke	73.0mm x 80.0mm
Compression Ratio	10.7:1
Front Brake	Single 320mm disc with two-piston caliper
Rear Brake	Single 240mm disc with single-piston caliper
Fuel Capacity	3.7 gallons
Fuel System	PGM-FI
Transmission	6-speed
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock
Front Tire	120/70-17
Rear Tire	160/60-17
Wheelbase	60.6 inches
Curb Weight	472 pounds
