Honeywell Esser 8010 - 12.3 Third-Party Detector Connectivity

Extinguishing Control Computer 8010 – 19-Inch
74 FB 798955.GB0 / 09.07
12.3 Third-party detectors via Reset module to
LMST 8010 - 19-Inch series 2
Third-party detectors, e.g. the line-type smoke detector Fireray 50RV (Part No. 761315) or 100RV
(Part No. 761316) are connected to the Extinguishing Control Computer 8010 - 19-Inch series 2 via the Reset
module (Part No. 781332 / 781333).
6
3
7
2
4
5
black
red
blue
white
yellow
green
Plug with cable
(lenght approx. 50cm)
1K
10K
R
END
R
ALARM
5
4
3
2
1
6
X2
X1
5
4
3
2
1
6
X8X7X6X5
X4X3
K1
Fit jumpers
Reset module
Gn +
Gn -
Detector zone input
Extinguishing Control Computer
standard detector zone
+24V
0V
Extinguishing Control Computer
external power supply or
DC/DC converter
(Min. 1A switch current)
Jumper X3, X5, X7, X8 fitted!
Jumper X4, X6 removed!
Connect cable shielding!
Observe wiring sequence!
For detailed informations and wirings refer to the technical manual of the Reset module.
