Galaxy Dimension Installer Manual
6-64
46 = Resistance Select
RIOs rev 1.2 and Smart PSUs rev 0.7 and above allow the zones to be programmed, with different resistance
preset values for zone status activation. This feature allows selection of End Of Line or Double Balanced zone
resistance types. The on-board zones can also be modified using this feature.
The “EOL/Dbl. Bal.” resistance types are selectable from this option. The system default value is 1k Fault
(Double Balanced). There are 10 preset pre-programmable resistance configurations:
1 = Preset 1 (BAL); 2 = Preset 1(EOL); 3 = Preset 2 (BAL); 4 = Preset 2 (EOL); 5 = Preset 3 (BAL);
6 = Preset 3 (EOL); 7 = Preset 4 (BAL); 8 = Preset 4 (EOL); 9 = 1K Fault (BAL); 10 = 1K Fault (EOL).
The tables that follows shows the resistance windows for each type:
51 - Parameters (cont’d)
Table 6-9. Preset value limits (ohms) - double balanced
Table 6-10. Preset value limits (ohms) - end of line
When a preset is selected, this will be the zone resistance range used by every zone on the system. Each zone
on the system can be further customised to a specific preset by using menu option 52.9, Resistance Select.
Option 01 - 1k Option 03 - 2k2 Option 05 - 4k7 Option 07 - 5K6 Option 09 - 1k Fault
Tamper S/C 0 - 800 0 - 1800 0 - 3700 0 -1400 0 - 800
Low Res 800 - 900 1800 - 2000 3700 - 4200 1400 - 2800 800 - 900
Normal 900 - 1200 2000 - 2500 4200 - 5500 2800 - 8400 900 -1200
High Res 1200 - 1300 2500 - 2700 5500 - 6500 8400 - 9800 1200 - 1300
Open 1300 - 12000 2700 - 12000 6500 - 19000 9800 - 12600 1300 - 3500
Fault - - - - 3500 - 4500
Masked 12000 - 19000 12000 - 15000 19000 - 22000 12600 - 22000 4500 - 19000
Tamper O/C 19000 - infinity 15000 - infinity 22000 - infinity 22000 - infinity 19000 - infinity
Option 02 - 1k Option 04 - 2k2 Option 06 - 4k7 Option 08 - 5k6 Option 10 -1k Fault
Tamper S/C 0 - 800 0 - 1800 0 - 3700 0 - 1400 0 - 800
Low Res 800 - 900 1800 - 2000 3700 - 4200 1400 - 2800 800 - 900
Normal 900 - 1200 2000 - 2500 4200 - 5500 2800 - 8400 900 - 1200
High Res 1200 - 1300 2500 - 2700 5500 - 6500 8400 - 9800 1200 - 1300
Fault - - - - 1300 - 4500
Masked 1300 - 12000 2700 - 12000 6500 - 19000 9800 - 19000 4500 - 19000
Open 12000 - infinity 12000 - infinity 19000 - infinity 19000 - infinity 19000 - infinity
