NOTES:
1. Where two identical events occur within 1 second, only one is logged.
2. Only the first occurrences of high resistance and low resistance events on each day are logged.
Subsequent activations are ignored until midnight of the same day. This is to prevent the log
from being filled with high and low resistance activations from a faulty zone.
The event log can be printed while accessing the Display Log option. Pressing the


 key while displaying an
event starts the printout from the displayed event and prints forward to the most recent event. The esc key
aborts the print out.
NOTE: A serial printer must be connected to the Galaxy panel via a printer interface module, the RS232
interface module, or the RS232 serial port.
Option 23 – System
This option provides a quick overview of the system configuration; two lines of information are displayed at a
time - the A and B keys are used to scroll through the entire list:
• Groups use the A and B keys to scroll through groups A1–8, B1–8, C1–8 and D1–8
• Group status U = Unset, S = Set, P = Part set and L = Locked-out for each of the groups
displayed;
NOTE: Enabling the Show Status option (refer to option 58 = KEYPADS) allows the group set status to
be displayed from the normal banner (when the system is set or unset) by pressing the  and # keys
simultaneously.
• Type Galaxy 48, 96, 264 or 520;
• Version version of software in Galaxy panel;
• RIOs fitted includes the on-board RIOs;
• Codes used includes the manager, engineer and remote codes;
• Keypads fitted 1–8 (Galaxy 48), 1–16 (Galaxy 96/264), 1–32 (Galaxy 520);
• Comms modules 1-7 (Telecom, RS232, ISDN, Ethernet, Int Telecom, Int RS232, Audio Module);
• Printer 0–1 (Printer Interface Module);
• MAX Modules gives the number of MAX modules on the system;
• DCM Modules gives the number of Door Control Modules on the system;
• MUX Modules gives the number of MUX Modules on the system
• Panel location up to 16 characters of text entered in System Text parameter (option 51.15.2).
23 - System
Level of User Code
10:24 SUN 01 JAN10:24 SUN 01 JAN
10:24 SUN 01 JAN10:24 SUN 01 JAN
10:24 SUN 01 JAN
K10 L7K10 L7
K10 L7K10 L7
K10 L7
K = Keypad
AB Line
Keypad Address
• Default Set gives the default settings set up in menu 51.17.
