Galaxy Dimension Installer Manual
H-1
Appendix H: Parts List Index
Parts List Index
Product N ame UK Part No Comments
Replacement PCB,s
GD-48 PCB
GD-96 PCB
GD-264 PCB
GD-520 PCB With expander
Accessories
Doorguard C075 Door isolation
Unit
Doorguard common key C075C All use same
key
Engineer keypad cable A136
Twisted pair 4-core cable W002
Serial Peripheral interface
Key
A227
PSU’s
Galaxy Power Unit P025
Galaxy Power RIO P026
EN G3 PSU Stand-alone P027
2-75A Power Block A270 Spare PCB
Galaxy Power RIO
Control PCB
A250 Spare PCB
Galaxy Power Unit
Control
A251 Spare PCB
PSU Control A252 Spare PCB
Keypad/KeyProx
Galaxy Mk7 Keypad CP037 With volume
control
Galaxy Mk7 KeyProx CP038 ASK format with
volum e control
Galaxy KeyProx HID CP028-01-H-B ASK/HID format
ASK prox card clamshell YX0-0005 Credit card
HID prox card YX0-0006 Credit card
ASK Keytag YX0-0004 Tear drop
ASK Grey Fob YX0-0020
Touch Center CP040
Remote Modules
RIO (PCB) A158-B
RIO (boxed) C072
Telecom Module E062-01
RS232 Module E055
RS232 Module (boxed) E054
Printer Interface A134 6 pin D IN
connector
Printer Interface A161 25 way sub D
connector
ISDN Module E077
Ethernet Module E080-2
RF RIO (boxed) C076
RF RIO (PCB) A215
Audio Controller C 080
Speake r-m ic Unit T P2-80 0G Y
Access Control
MAX Reader MX01
MAX Flush mounting kit MX02
MAX3 Proximity Reader MX03
MAX3 vandal resistant
cover
MX03-VRC
MAX3 extension read
head
MX03-ERH
MAX3 hand-held
programmer
MX03-HP
MAX3 Mounting plate MX03-MP
MAX card with magnetic
stripe
YX0-0001
Product N ame UK Part No Comments
MAX card YX0-0002
MAX keytag YX0-0004
MAX programming
module
YX0-0007
Door Control module C080
Door Control Module with
PCU
C081
SPI Key Programmer C087
Software Packages:
R emote Servicing Suite
Licencing Kit R030 KIT
Upgrade R030-CD
Licence Kit (Dongle) R031-01-KIT
Upgrade (Dongle) R031-CD
User Management Suite
Licence Kit R032-01-KIT
Upgrade R032-CD
Licence Kit (Dongle) R033-01-KIT
Upgrade (Dongle) R033-CD
Literature
Galaxy Dimension
Installer manual
IE1-0063
Galaxy Dimension User
Guide
IU 1-0063
Galaxy Dimension Quick
User Guide
IG1-0064
Galaxy Dimension Quick
Start Guide
IG1-0063
Door Control Module
Instructions
II1-0800
Audio Controller
Instructions
II1-0801
Touch Center Instructions II1-0802
Touch Center User Guide II8-0803

Honeywell Galaxy Dimension series Specifications

General

Model	Galaxy Dimension series
Users	Up to 250
Partitions	Up to 8
Operating Temperature	-10°C to +55°C
Compatibility	Honeywell Galaxy accessories and peripherals
