Galaxy Dimension Installer Manual
6-160
Option 63 – Options
The Options function allows the Galaxy to be divided into group subsystems.
63 - Options
Figure 6-12. Options
Options
1 = Groups
1 = Group Mode
0 = Disabled
1 = Enabled
2 = Setting Logic
A/B to move to group and ent to select.
Number keys to toggle:
- = status of group unimportant
S = Group must be set to allow group to set.
3 = Group Name
A/B to move to group and ent to select.
# = toggle upper case, lower case or library text.
* = delete last character.
A/B = move to character/word.
ent = assign character/word.
esc = save programming.
63.1=Groups
On selecting Options, the keypad displays 1 = Groups; press the ent key to select this function.
1 = Group Mode
This option is used to enable the Groups function (default is 0 = Disabled). When enabled, the system
options that are eligible for group programming are then made available throughout the menu, otherwise they
do not appear.
Enabling Groups
On selecting 1 = Enabled, press the ent key to accept the programming and return to the previous menu
type.
NOTE: You must return to the Engineer Mode banner for groups to be fully enabled.
Disabling Groups
The Group Disabled feature operates as follows:-
When disable groups is selected in menu option 63.1.1 two option are given:-
1. Reset Groups
2. Disabled
If option 1 - Reset Groups is selected the engineer is prompted to confirm the selection. If confirmed, by
pressing the enter key, all group programming, for all the panel features, are reset to A1. When engineering
mode is exited a warning message is displayed (ATT!!! GRPS OFF, SYS. OP. IMPACT) alerting the
engineer that groups have been reset and there will be an impact on the operation of all functions not pro-
grammed as group A1. This warning message will be displayed until the ESC key is pressed by the engineer,
acknowledging the warning.
NOTE: When group programming is re-enabled all previous group programming will not be restored.
