2 = Setting Logic
The Setting Logic option restricts a group from setting by determining which other groups must be set before
it can set. For example, group 1 may be prohibited for setting unless groups 3, 7 are already set. The Set-
ting Logic is individually defined for each group.
Programming Setting Logic
On selecting the Setting Logic option, group 1 is displayed. Use the A or B keys to move to the required
group or directly select it by pressing the required group number; press the ent key to access the group. On
selecting the group, the current Setting Logic details are displayed:
• S below a group means that it must be set to allow the selected group to set
• a dash (–) below the group indicates that the set status of this group is not important.
Toggle the status between S and – by pressing the number key. When the required setting logic pattern has
been defined press the ent key to accept the programming and return to the previous menu type.
Multi-group Systems
The larger Galaxy panels have 32 groups; these are displayed on the keypad in block of eight groups, sub-
divided into A, B, C and D:
Table 6-28. Groups
Use the A or B key to move between the group blocks; press keys 1 – 8 to toggle the Setting Logic for the
relevant groups in each block.
kcolBpuorGspuorGlacisyhP
8-1A8-1
8-1B61-9
8-1C42-71
8-1D23-52
63 - Options (cont’d)
If option 2 - Disabled is selected the engineer is prompted to confirm the selection. If confirmed, by pressing
the enter key, all group programming, other than A1 will be disabled (zones, outputs, links, users). When
engineering mode is exited a warning message is displayed (ATT!!! GRPS OFF, SYS. OP. IMPACT)
alerting the engineer that groups have been disabled and there will be an impact on the operation of all areas
not programmed as group A1. This warning message is displayed until the ESC key is pressed by the engi-
neer, acknowledging the warning.
NOTE: If this option is selected, when group mode is re-enabled all previous group programming will be
restored. However, while group mode is disabled, a zone not programmed to group A1 will not
operate normally on the system. It is strongly recommended that, whenever possible, groups are
always reset to A1 when disabling groups.
