Honeywell Galaxy Dimension series User Manual

F-2
Galaxy Dimension Installer Manual
Specifications (cont’d)
Modules Weight Order Code
Galaxy Keypad (Mark VII)...................................................................... 190 g CP027
Size: …………………………………................. 149 x 91 x 31 mm (L x B x H)
Galaxy Keyprox (Mark VII)..................................................................... 190 g CP028
Size........................................................................ 149 x 91 x 31mm (L x B x H)
Keypads Material ................................................................................... PC + ABS
Keypad Colour ....................................................................................... Neutral
Galaxy TouchCenter ....................................................................... 500 g CP040
Size ............................................................. 182 x 128 x 34 mm (L x B x H)
MAX3 (Boxed)........................................................................................ 267 g MX03
Size..................................................................... 185 x 120 x 48 mm (L x B x H)
Galaxy RIO (Boxed) .................................................................................300 g C072
Size: ......................................................................150 x 162 x 39 mm (L x B x H)
Galaxy RF RIO (Boxed) ................................................................... 270 g C076
Size ............................................................. 150 x 162 x 39 mm (L x B x H)
RS232 Module (Boxed) .......................................................................... 823 g E054
Size: .....................................................................180 x 155 x 35 mm (L x B x H)
Door Control module (Boxed) No PSU ............................................... 270g C080
Size.................................................................... 150 x 162 x 39 mm (L x B x H)
Door Control module (Boxed) with PSU ...............................................300g C081
Size.................................................................... 150 x 162 x 39 mm (L x B x H)
Line Expander ......................................................................................... 820g A226
Size: .....................................................................180 x 155 x 35 mm (L x B x H)
Doorguard ................................................................................................ 995g C075
Size: .....................................................................150 x 185 x 40 mm (L x B x H)
Printer Interface (6-Way DIN Plug) ...................................................... 120 g A134
Printer Interface (25-Way D Plug) ........................................................ 130 g A161
Box Size: .............................................................. 75 x 52 x 28 mm (L x B x H)
Cable Size: ............ 2m for 4-Way IDC, and 0.3m for 6-Way/25-Way plug.
PCBs Weight Order Code
2-75A Power Block ................................................................................. 163 g A270
Size: .....................................................................115 x 102 x 33 mm (L x B x H)
Galaxy Power RIO Control...................................................................... 118 g A250
Size: .....................................................................120 x 120 x 43 mm (L x B x H)
Galaxy Power Unit Control..................................................................... 118 g A251
Size: .....................................................................120 x 120 x 43 mm (L x B x H)
PSU Control.............................................................................................. 118 g A252
Size: .....................................................................120 x 120 x 43 mm(L x B x H)

Honeywell Galaxy Dimension series Specifications

General

Model	Galaxy Dimension series
Users	Up to 250
Partitions	Up to 8
Operating Temperature	-10°C to +55°C
Compatibility	Honeywell Galaxy accessories and peripherals
