Galaxy Dimension Installer Manual
6-151
Option 57 – System Print
The System Print option allows the details of the system programming to be printed. There are 2 options for
the printer output:
1 = Printer Module
2 = Int RS232 1
From either option, the specific details of one or all of the menu options in the following table can be selected:
57 - System Print
noitpOuneM.oNuneM
10ataDmetsyS32
20sedoC24
30sretemaraP15
40senoZ25
50stuptuO35
60skniL45
70noitacinummoC65
80NDSI3.65
90spuorG36
01sdapyeK85
11sremiT56
21goLtnevE22
31)11-1smeti(llA
Selecting a Print Option
The required print option is selected by entering the option number 01 – 12 or by using the A and B keys and
then pressing ent. When printing option 11 = EVENT LOG, the system prompts for Groups to be selected;
the print shows only those events logged for the groups selected. The print can be aborted at any time by
pressing the esc key.
NOTE: A serial printer on line must be connected to communication line 1 of the Galaxy before the print
option is selected. If the printer is off-line or is not connected, the PRINTER off-line / ESC to
abort message is displayed. Press the ESC key and correct the problem.
Printing Timers
Printing 10 = Timers gives details of all the times that have been assigned in option 65 = TIMERS; this
includes the autoset time, the pre-warning period and lockout times.
Table 6-25. System Print Options
