Galaxy Dimension Installer Manual

6-70

51 - Parameters (cont’d)

74 = Backup Link

If the Ethernet fails to report, this parameter, when enabled, allows the communication to revert to Telecoms.

75 = Backup Timer

This is the time that the backup link is active. The time can be set from 0-300 seconds. The default is 90

seconds.
