Galaxy Dimension Installer Manual
6-124
3 = ISDN Module
Figure 6-8. ISDN Programming Structure
56 - Communications (cont’d)
3 = ISDN
01 = Primary
1 = Default Tel No
2 = Default Acc No
3 = Dial Type
1 = Analogue
2 = Digital
3 = X.25
1 = TEI
2 = LCGN
3 = LCN
4 = Polling Rate
1 = None
2 = 90 secs
3 = 15 mins
4 = 60 mins
5 = Programmable
4 = RAM
Option not available
4 = Format
02 = Secondary
1 = Default Tel No
2 = Default Acc No
3 = Dial Type
4 = Format
5 = Copy Primary
6 = Alternate
1 = Disable
2 = Enable
03 = ISDN Type
1 = Point to Multipoint
2 = Point to Point
04 = ISDN Snatch
1 = Hardware
2 = Software
1 = Always Snatch
2 = Never Snatch
3 = Snatch if Line Fail
1 = Disabled
2 = Enabled
05 = Autotest
5 = CUG Index
1 = DTMF
2 = SIA
3 = Microtech
4 = Contact ID
6 = X.25 Protocol 1
7 = X.25 Protocol 2
5 = Robofon
06 = Engineer Test
07 = Line Fail
2 = Line Volts Only
3 = Layer 1 Only
4 = Volts and Layer 1
5 = Volts or Layer 1
08 = Fail to Comm
09 = Remote Access
10 = Alarm Monitoring
1 = None
1 = Access Time
1 = Off
2 = All Unset
3 = Any Set
4 = Any Time
2 = Mode
1 = Direct Access
2 = Manager Authorize
3 = Call Back
1 = Start Time
2 = Intervals
3 = Int. Test
4 = Group condition
1 = Trigger
2 = Phone Number
3 = Account Number
11 = Backup Module
1 = Off
2 = Ext. Telecoms
3 = Ext. RS232
4 = Ethernet
5 = Int. Telecom
6 = Int. RS232 1
