69 - Access Control (cont’d)
Figure 6-15. Access Control Programming Structure (sheet 2)
69.1 = Access Mode
The Access Control function can either be set to 0 = Disabled or 1 = Enabled. The default is Enabled.
The following pages describe the MAX menu programming functions followed by the Door Control Module
programming functions.
3 = DCM
1 = DCM Parameters
DCM XXX (select)
69 = Access Control (cont'd)
1 = Descriptor ABCDE_ (9 characters)
2 = Operation
3 = System Group
4 = Facility Code
5 = Reader (01 or 02)
0 = Entry & Exit
1 = Entry & Entry
2 = Single Entry
1 = Code 1
2 = Code 2
3 = Code 3
4 = Code 4
01 = Descriptor (ABCDE_ 9 characters)
02 = Relay Duration - 0-60 seconds (default = 05)
03 = Open Timeout - 1-60 seconds (default = 10)
04 = Group
Config
1 = Alarm Group
2 = Group Restrict
3 = Exit Group
05 = Emergencies
06 = AntiPassBack
1 = Mode
0 = Off
1 = Soft
2 = Hard
2 = Timeout 00 (0-60) minutes
3 = Forgive
07 = APB (by group)
08 = Security
1 = Nightlock
00-67 weekly schedules
2 = Unlock Time
00-67 weekly schedules
3 = Dual Mode
0 = Disabled
1 = Card and Card
2 = Card and Pin
4 = Dual Time - Option not available
09 = Menu Recall
1 = Menu Function 11-71 (** = not used)
2 = Menu Mode
0 = Disabled, 1 = Enabled
1 = Triple Repeat
2 = Recall Button
3 = Keypad
- Keypad
**
# = Enable
2 = Card Format
3 = Start Point
4 = User Field
0 = 26bit
1 = Crp 1K 35bit
2 = 37bit no FC
3 = Northern 34 bit
4 = Custom
1 = Format Name
2 = Card Length
1 = 26 Bit, 2 = 27 Bit, 3 = 32 Bit, 4 = 34 Bit
5 = 35 Bit, 6 = 37 Bit, 7 = 40 Bit
13 (1-33)
1 = Field Position 00 (1-13)
2 = Field Length 09 (1-13)
