Event Log (cont’d)
NOTE: M = Mandatory. NM = Non-Mandatory
NOTE: A plus (+) means an event has started. A negative (-) means an event has finished.
KEYPAD TEXT DESCRIPTION Trigger Event
LOC WRITE Diagnostics local write event None M
+LOCKTIMER Lockout timer activated. None NM
–LOCKTIMER Lockout timer de-activated. None NM
+LOG Log zone activated (opened). 16. Log NM
–LOG Log zone de-activated (closed). 16. Log NM
LOG 90% Event log 90% full Always TR NM
LOG DELAY Log Delay zone has been activated (opened) for longer than the Delay Alarm time. 16. Log NM
+LOW RES Zone changing to low resistance (900 to 800 Ohm). 15. Trouble M
–LOW RES Zone changing from Low Resistance to Normal Closed (800 to 900 Ohm). 15. Trouble M
+LOW VOLTS Voltage of AUX outputs has dropped below 10V. 13. Elec Status
15. Trouble
M
+MASK Mask zone activated (opened). 4. Security M
–MASK Mask zone de-activated (closed). 4. Security
18. Zone restoral
M
MASKED Zone masked. Detector has activated its masking output. 15. Trouble
20. Fault
M
MAX ALARM MAX alarm — door forced. 4. Security
17. Max Tag
M
MAX TAMP MAX Tamper 9. Tamper M
MEM RESET Memory Reset (Restart) to factory default settings (Cold Start). 13. Elec Status NM
+MISSING Module Missing its AB (RS485) communications. 9. Tamper M
–MISSING Module that was Missing now has its AB (RS485) communications re-established. 9. Tamper
18. Zone restoral
M
MOD CODES Modify Codes menu (Menu Option 42) has been accessed. 14. Menu Access M
MOD REM Remote Servicing menu (Menu Option 47) has been accessed. 14. Menu Access NM
MOD SUMMR Modify Summer menu (Menu Option 43) has been accessed. 14. Menu Access NM
MOD T/D Modify Time/Date menu (Menu Option 42) has been accessed. 14. Menu Access M
MOD TMRS Modify Timers Control menu (Menu Option 45) has been accessed. 14. Menu Access NM
NEW T/D New Time/Date after modification. Always TR M
OMIT ATM1 Omit all ATM1 zones. 8. Omit M
OMIT ATM2 Omit all ATM2 zones. 8. Omit M
OMIT ATM3 Omit all ATM3 zones. 8. Omit M
OMIT ATM4 Omit all ATM4 zones. 8. Omit M
OMIT VIBS Mass omit of vibration zones. 8. Omit M
OMIT ZONE Omit zones menu (menu option 0 in Quick Menu or menu option 11 in Full Menu has been
accessed.
None M
OMITTED Zone has been omitted 8. Omit M
OVERRIDE Event has been overridden to set the system None M
OVWR SITE Remote overwrite of the site has occured via Remote Servicing or RS232 module None M
P.AUDIBLE PA Audible zone activated (opened). None NM
PA PA zone activated (opened) 1. PA/Duress M
