INTELLIDOX DOCKING MODULE USER MANUAL || DETECTOR OPERATIONS

HONEYWELL PAGE 47 OF 119

Detector Operations Menu

After the detector is recognized and automated procedures are completed, the detector

operations menu and What do you need to do? are displayed.

Press or on the module keypad to select a menu item, and then follow on-screen

instructions to perform the selected procedure.
