Revision 5.0 ST 800 Series HART/DE Option User’s Manual Page 43
Online/Device
Setup/Detailed Setup
(Continued …)
PILD/PILD
Select the PILD configuration:
“Enable”: enables PILD feature/functionality
“Disable”: disables PILD feature/functionality
PILD/Application
(App)
Provides option for user to select application type so
that default PILD Configuration parameters for selected
Application Type(SWIN....) are auto selected by
Transmitter.
Possible Application Types are:
• DP flow application (Not applicable for
Absolute and Gauge Transmitter.
• Marine Level
• Bubbler Level
• Other (Default Factory Configuration)
PILD/Sampling
Window (SWIN)
The sampling window of PILD in minutes, which
determines a cycle of PILD runs for both training and
monitoring mode.
Enumeration: 3, 6, 9, 12, 15 minutes
PILD/Up Limit
(UL)*
The up limit of PILD factor for normal status.
Valid range is from 0.50 to 1.00.
PILD/Down Limit
(DL)*
The down limit of PILD factor for normal status.
Valid range is from BL to 0.50.
PILD/Blockage
Limit (BL)*
The both sides blockage Limit of PILD factor.
For AP/GP transmitter, BL is not available/applicable,
because there is only one side.
Valid range is from 0.00 to DL.
PILD/Cut Off
Frequency
Cut Off Frequency (HPF f0) configures the cut off
frequency of a high pass filter for dynamic process.
This is used to take noise fluctuation of PV is kept after
filtering.
Valid range is from 0.0 to 5.0..
Online/Device
Setup/Meterbody
Selections
Displays detailed information pertaining to the
Meterbody, including construction configuration,
materials of construction, fill fluids, and process
connection details.
*This parameter can be changed when PILD is disabled. When PILD is enabled user can still change the
parameter if PILD is in Monitoring mode and not in Training mode
