l Prefix and Suffix data is always added on after stripping is complete, and is not affected by any stripping settings.
l If the stripping configuration results in a 0 length bar code, a good beep will still be emitted, since bar code data was read
from the scanner.
Match List Rules
The data in the match list is processed by the rules listed below:
l Strings in the list will be searched in the order they appear in the list. If the list contains ABC and AB, in that order,
incoming data with ABC will match first, and the AB will have no effect.
l When a match between the first characters of the bar code and a string from the list is found, that string is stripped from
the bar code data.
l Processing the list terminates when a match is found or when the end of the list is reached.
l If the wildcard * is not specified, the string is assumed to strip from the beginning of the bar code data. The string ABC*
strips off the prefix ABC. The string *XYZ will strip off the suffix XYZ. The string ABC*XYZ will strip both prefix and
suffix together. More than one * in a configuration string is not allowed. (The User Interface will not prevent it, but results
would not be as expected, as only the first * is used in parsing to match the string.)
l The question mark wildcard ? may be used to match any single character in the incoming data. For example, the data
AB?D will match ABCD, ABcD, or AB0D, but not ABDE.
l The data collected is saved per symbology configured. The Symbology selected in the Symbologies dialog defines the
symbology for which the data is being configured.
l Note that the Code ID (if any are configured) is ignored by this dialog, regardless of the setting of Strip: Code ID in the
Symbologies dialog. According to the sequence of events (specified above), the Code ID must not be included in the bar
code data being matched, because when the matching test occurs, the Code ID has already been stripped. If Strip
Code ID is disabled, then the bar code data to match must include the Code ID. If Strip Code ID is enabled, the data
should not include the Code ID since it has already been stripped.
3-88
