Gobi Connection Manager
Start > Settings > Control Panel > Gobi Connection Manager or
Tap the Gobi Connection Manager Desktop Icon or
Tap the Gobi Connection Manager icon in the system tray or
Tap Start > Programs > LXEGobiCM > LXEGobiCMExe
Set parameters for optional internal WWAN module.
Home View connection status and select firmware.
CDMA Use this tab to activate a CDMA carrier such as Verizon.
UMTS Use this tab to test and save connection parameters.
GPS View GPS statistics.
About View information on the WWAN card.
The Gobi Connection Manager tray icon indicates the status of the connection in dark blue bars. If you hover the mouse pointer
over the Connection Manager Taskbar icon, the current signal level and radio interface are displayed.
Note: The similar Summit wifi icon in the task bar uses red, yellow and green bars.
There is no WWAN connection present.
-105 dbm to -86 dbm signal strength
-85 dbm to -66 dbm signal strength
-65 dbm to -46 dbm signal strength
-45 dbm or higher signal strength
Initial Use
Some carriers such as AT&T and T-Mobile require a SIM card for use on their networks. Other carriers such as Verizon use a
CDMA network and must be activated. Please refer to the sections below for more details.
SIM Card Installation
Depending on the carrier, a SIM card may be necessary for WWAN connection. To install a SIM card:
1. Place the Thor VM1 in Suspend.
2. Remove the Thor VM1 from the Quick Mount Vehicle Dock.
3. Place the Thor VM1 face down on a stable surface.
4. Use a Phillips screwdriver (not supplied) loosen the screws and then remove the tethered access panel with the SIM
label. This panel is on the right hand side when the Thor VM1 is face down with the top away from the user.
5. Install the SIM card in the slot.
6. Reattach the access panel, torquing the screws to 4 to 5 inch pounds.
3-106
