Operand
The math operator is performed either on operand 1, or on operand 1 and
operand 2. The number of operands used depends on the math operator you
select. For example, add requires two operands while invert requires only
one operand.
Operand lets you select from channels, functions, waveform memories, or a
constant.
•
If the operand waveforms have different record lengths, the function uses
the shortest record.
•
If two operands have the same time base scale, the resulting function has
the same time scale which results in the proper time scale for the function.
•
Constant operands have the same time scale as the associated waveform
operand.
•
A waveform function operand is acquired even if its display is turned off.
•
Function 1 is allowed as an operand for function 2. This allows you to
construct equations with up to two operators and three operands.
Math Menu
Define Function
12–6
