HP 54710A - Data; Setup Factors

Data
Data allows you to choose to print just the graticule area, the entire screen,
or just the setup factors to a printer or disk.
Graticule
Graticule prints only the waveform viewing area (graticule area) to the
printer or to the disk. If you turn on setup factors, the channel, time base,
and trigger setups are also printed.
Screen
Screen prints the entire screen area to a printer or a disk. If you turn on
setup factors, the channel, time base, and trigger setups are also printed.
Factors
Factors prints only the channel, time base, and trigger setups to the printer
or to the disk.
Setup Factors
Setup factors is available when the Data softkey is set to either graticule or
screen. When set to on, Setup factors prints the channel, time base, and
trigger setups along with the graticule or screen data to the printer or to the
disk.
Setup factors are not included in the PCX, GIF, or TIF file formats.
Setup Print Menu
Data
15–8
