HP 54710A - Mode; Axis

Mode
The
mode
softkey turns the display of the histogram off and on. The off
selection turns off the display of the histogram, while waveform turns on the
display of the histogram. If the data base for the histogram is not already
built (mask testing and color graded display turned off),
waveform
starts
building the data base and the histogram. If the data base is already built,
waveform
displays a histogram of the data in the data base that is windowed
by the histogram markers. The data base may be reset by pressing the Clear
display hardkey.
Axis
The
axis
softkey orients the histogram vertically or horizontally. Vertical
places the histogram at the left side of the graticule, which allows for voltage
measurements. Horizontal places the histogram at the bottom of the
graticule area, which allows for timing measurements.
Histogram Menu
Mode
24–6
