Setup Memory
Setup memory selects which of the ten nonvolatile memory locations you
want to store the front-panel setup to, or recall the front-panel setup from.
The setup memories are numbered 0 through 9.
Setup memories allow you to easily recall a previous setup for viewing a
waveform for further waveform comparison or analysis. You can also use the
setup memories to save a front-panel setup in case someone else changes the
setup when they are using it.
In situations where you need more than ten front-panel setups, or in work
groups where you want to make sure that someone does not accidentally
overwrite your saved setups, you can save setups to a disk.
See Also
Chapter 7, "Disk," for information on saving to a disk.
Save
Save stores the present front-panel setup to a selected setup memory. Any
previous settings saved to that setup memory are overwritten. The message
"Setup saved" is displayed at the top-left corner of the screen indicating the
setup was saved.
Setup Menu
Setup Memory
14–3
