Normal Accuracy Calibration Level
Normal accuracy calibration level refers to the level of accuracy that is
achieved when a plug-in is installed in a slot of a mainframe, but has not been
calibrated to best accuracy in that particular slot.
The oscilloscope uses the mainframe calibration factors and the plug-in
calibration factors to determine the normal calibration factors for that plug-in
in that slot.
The intent of this level of calibration is to allow any plug-in to be inserted in
any mainframe slot and still achieve a typical vertical accuracy of
±
3%.
For two-wide plug-ins, like the HP 54721A, the interleaving of the two
mainframe slots is performed during the best accuracy calibration.
Therefore, the real-time sampling mode is typically not useful in the normal
accuracy mode. For accurate results, a best accuracy calibration must be
performed to use two-wide plug-ins in the real-time mode.
See Also
"Best Accuracy" in this chapter for details on the best accuracy calibration.
"Normal Accuracy" in chapter 16 for more details on the normal accuracy
specifications.
Calibration Overview
Normal Accuracy Calibration Level
5–5
