Specifications
The following are specifications used to test the HP 54700-Series
mainframes. Specifications are valid after a 20 minute warm-up period.
Time base
Time-Interval Measurement Accuracy
1
Real Time
±
[(0.2)(sample interval)
+
0.007% of delta-time marker
reading].
Equivalent Time (16 averages)
±
(30 ps
+
0.007% of delta time
marker reading)
Front Panel
Calibrator
dc Output
Adjustable output range
−
2.5 V to
+
2.5 V when terminated into 50
Ω
.
Output Delta Voltage Accuracy
±
(0.2% of delta voltage output)
1) Time interval measurement accuracy includes error sources such as time base
inaccuracy, aperture uncertainty/sample clock phase jitter, reconstruction filter
uncertainty (real-time only), trigger interpolation jitter, and channel-to-channel skew.
Real-time time-interval accuracy applies for input rise times greater than 1.4
multiplied by the sample interval.
Specifications and Characteristics
Specifications
16–3
