The real-time acquisition mode has an advantage in measuring the true rise
time, delay, or other time intervals on jittering signals. In the real-time
acquisition mode, a complete record of each transition is acquired on every
trigger. The oscilloscope can make accurate measurements on these records
and can calculate and display the statistics of measurements on many
transitions.
Measurements
Statistics
13–29
