For time-interval measurements between edges of opposite polarity, the
errors caused by dc level errors add rather than cancel as shown in
figure 13-14. The time errors in locating the leading edge and trailing edge of
the pulse reinforce rather than cancel.
Edges of Opposite Polarity Reinforce dc Errors
Figure 13–14
Measurements
Time-interval measurements
13–33
