Amplitude Measurements
For best amplitude accuracy on peaks
1
In the channel menu, make sure the source impedance and probe
attenuation are set correctly for your application.
2
In the acquisition menu, set the Sampling mode to real time and set
Interpolate to off.
3
In the channel menu, set the Scaling for almost full scale deflection.
4
In the FFT menu, use the flattop window.
5
Press the shift key, then the More meas key on the keypad. Then, make an
FFT magnitude measurement.
