4-50 ES User’s Guide
Using Instrument Functions
Customizing the Display
The following display annotation areas can be modified or turned on or
off:
• Measurement title and clock
• Measurement channel annotation
• Frequency annotation
• Marker annotation
• Marker number
• Y-axis labels
• Y-axis (relative or absolute scale)
• Limit test Pass/Fail text
• Limit icon
• Limit test Pass/Fail indicator position
Measurement
Title and Clock
The measurement title area consists of two lines of text. In the default or
preset state, this annotation area is toggled off. When the title mode is
initially turned on—by pressing
—line 1 is empty and the clock (date and time of day)
is assigned to line 2.
The menu allows you to customize these two lines.
The clock can be shown on line 1, line 2, or can be turned off. You can
enter up to 30 characters of text on either or both lines.
NOTE When the display is in split display mode, line 1 is shown at the top of
the measurement channel 1 screen, and line 2 is shown at the top of the
measurement channel 2 screen.
To turn the measurement title and clock on or off, press
.
DISPLAY
DISPLAY
