ES User’s Guide 4-51
Using Instrument Functions
Customizing the Display
Measurement
Channel
Annotation
The measurement channel annotation at the top of the display screen
can be modified through the use of SCPI commands. See the Automating
Measurements User’s Guide Supplement for more information.
To turn the measurement channel annotation on or off, press
.
Frequency
Annotation
The frequency annotation at the bottom of the display (X-axis) can be
modified through the use of SCPI commands. See the Automating
Measurements User’s Guide Supplement for more information.
To turn the measurement channel annotation on or off, press
.
Marker Annotation The marker annotation that appears in the upper right corner of the
display can be turned on or off by pressing
.
Marker Number The marker numbers that appear above or below the marker symbols,
can be turned on or off by pressing
.
Y-Axis Annotation Press
to toggle the y-axis annotation and values: in ABS
mode, the absolute value of each horizontal graticule line is indicated; in
REL mode, the value of each horizontal graticule line is indicated relative
to the value of the reference line.
To turn on or off the y-axis annotation, press
.
Limit Test
Pass/Fail Indicator
The limit test pass/fail indicator can be moved to any position on the
display screen. To move the position of the pass/fail indicator, press
. Use the
and softkeys to
position the pass/fail indicator where desired.
To turn the pass/fail indicator text on or off, press
.
To enable or disable the display of the limit fail indicator, , press
.
DISPLAY
DISPLAY
DISPLAY
DISPLAY
DISPLAY
DISPLAY
DISPLAY
DISPLAY
DISPLAY
