8-4 ES User’s Guide
Hardkey/Softkey Reference
Numeric Entries
Softkey in the system impedance menu. Selects 75 ohms as the system
impedance.
Refer to “When to Change the System Impedance” on page 3-12 for
more information.
Access Keys:
Softkey in the cal kit menu of 50 ohm instruments. Selects the type of
cal kit as 7–16. This cal kit will work for both male and female
connectors.
See Chapter 6, “Calibrating for Increased Measurement Accuracy,” for
more information.
Access Keys:
NOTE By convention, cal kits indicate the sex of the port
with which they are used. For example, the
default cal kit for the analyzer is type-N female
because the front panel RF ports are female (the
calibration standards, in turn, have male
connectors).
Ω
CAL
CAL
To Next Page
