HP 8712ET User Manual

8-12 ES User’s Guide
Hardkey/Softkey Reference
B
Softkey in the marker search menu. Automatically calculates −3 dB
(default) or other user-specified bandwidth, center frequency, and Q of
a bandpass filter.
See “Using Markers” on page 4-3 for more information.Access Keys:
Softkey in the select copy port menu. Sets the transmission baud rate
of the analyzer for serial devices. Make sure the rate you set matches
the requirement of the output device (see its manual for details).
Access keys:
Softkey in the system configuration menu. Sets the analyzer beeper
volume from off (0) to high (100). The default is 90.
Access keys:
Hardkey located to the left of the disk drive. An appropriate place to
begin measuring any of the four types of devices in the begin menu.
Recommended for one channel measurements.
See “Using the BEGIN Key to Make Measurements” on page 3-14 for
more information.
Softkey used to define a limit line.
See “Using Limit Testing” on page 4-28 for more information.
Access Keys:
or
Softkey used to define a limit line.
See “Using Limit Testing” on page 4-28 for more information.
Access Keys:
or
Softkey in the BOOTP setup menu. When toggled to ON, enables a
BOOTP request when the analyzer boots up. Default setting is OFF.
See The LAN Interface User’s Guide Supplement for more information.
Access Keys:
Bandwidth
MARKER
Marker Search
Baud Rate
HARDCOPY
Select Copy Port
Beeper Volume
SYSTEM OPTIONS
System Config
BEGIN
Begin
Frequency
DISPLAY
Limit Menu
Add Limit
Add Max Line
Add Min Line
Begin Limit
DISPLAY
Limit Menu
Add Limit
Add Max Line
Add Min Line
BOOTP on OFF
SYSTEM OPTIONS
LAN
BOOTP Setup
