8-32 ES User’s Guide
Hardkey/Softkey Reference
F
Softkey in the system bandwidth menu. This is the narrowest system
bandwidth available. (Medium wide is the default system bandwidth.)
See Chapter 5 for information on how system bandwidth can affect
your measurements.
Access Keys:
Softkey in the marker math menu. Calculates the flatness of a
user-defined trace segment.
See “To Use Marker Math Functions” on page 4-18 for more
information.
Access Keys:
Hardkey in the CONFIGURE area. Pressing this key displays a menu
of choices for the display format of your measurement.
The choices available are: Log Mag, Lin Mag, SWR, Delay, Phase,
Smith Chart, Polar, Real, Imaginary, and Impedance Magnitude. For
more information on each of these choices, see its entry in this chapter.
Softkey in the format disk menu. Formats a disk in the analyzer’s
built-in disk drive in DOS format.
See “Formatting a Floppy Disk” on page 4-67 for more information.
Access Keys:
Softkey in the file utilities menu. Displays the format disk menu to
select either the internal non-volatile memory, internal volatile
memory, or 3.5” floppy disk (in the analyzer’s built-in disk drive).
Access Keys:
Softkey in the format disk menu. Formats the internal non-volatile
RAM disk.
CAUTION Formatting the internal non-volatile RAM disk
erases all existing files and directories on the
disk.
Access Keys:
AVG
MARKER
FORMAT
SAVE RECALL
SAVE RECALL
SAVE RECALL
