ES User’s Guide 8-33
Hardkey/Softkey Reference
F
Softkey in the format disk menu. Formats the internal volatile RAM
disk.
CAUTION Formatting the internal volatile RAM disk erases
all existing files and directories on the disk.
Access Keys:
Hardkey in the SOURCE area. Displays the frequency menu which
allows you to enter the frequency range for your measurement. Also
allows you to change the resolution of the displayed frequency.
See “Entering Measurement Parameters” on page 2-4 for an example
of how to enter frequency range.
Softkey in the annotation options menu. Toggle ON if you want to view
the frequency annotation at the bottom of the display.
See “Customizing the Display” on page 4-45 for more information.
Access Keys:
Softkey in the add max point and add min point menus. Sets the
frequency of a limit point.
See “To Create a Single Point Limit” on page 4-32 for an example of
how to set a limit point.
Access Keys:
or
Softkey in the menu. This key is used to return the analyzer
to frequency sweep mode, after it has been used in power sweep mode.
Softkey in the BOOTP setup menu. Selects FTP as the file transfer
protocol used to transfer a boot file from a BOOTP server to the
analyzer.
See The LAN Interface User’s Guide Supplement for more information.
Access Keys:
SAVE RECALL
FREQ
DISPLAY
DISPLAY
SWEEP
SYSTEM OPTIONS
