ES User’s Guide 8-57
Hardkey/Softkey Reference
M
Softkey in the mkr limits menu. Toggle to ON if you want to enable
marker limit testing.
See “To Use Marker Limit Functions” on page 4-32 for more
information.
Access Keys:
Softkey in the limit menu. Displays the marker limits menu where
limit testing can be placed on statistics, flatness marker searches, and
delta amplitude or frequency.
See “To Use Marker Limit Functions” on page 4-32 for more
information.
Access Keys:
Softkey in the annotation options menu. Allows you to toggle the
marker numbers (but not the triangular indicators) on or off.
See “Customizing the Display” on page 4-45 for more information.
Access Keys:
Softkey in the define graph menu. When on (default setting), prints or
plots contain marker symbols.
NOTE or must
be selected for marker symbols to print or plot.
Access Keys:
Softkey in the define hardcopy menu. Defines the hardcopy output as a
table of marker values (frequency and amplitude).
Access Keys:
Softkey in the max search menu. Places the active marker at the
frequency point of maximum amplitude. If tracking is off, the marker
remains at that frequency. If tracking is on, the marker moves to the
maximum point with each sweep.
See “Using Markers” on page 4-3 for more information.
Access Keys:
Mkr Limit
on OFF
DISPLAY
Limit Menu
Mkr Limits
Mkr Limits
DISPLAY
Limit Menu
Mkr Number
ON off
DISPLAY
More Display
Annotation Options
Mkr Symbol
ON off
Graph and Mkr Table
Graph Only
HARDCOPY
Define Hardcopy
Define Graph
Mkr Table Only
HARDCOPY
Define Hardcopy
Mkr
−
> Max
MARKER
Marker Search
Max Search
