ES User’s Guide 8-97
Hardkey/Softkey Reference
V
V
Softkey in the more cal menu. Enters the velocity factor used by the
analyzer to calculate equivalent electrical length. Values entered
should be less than 1, however the analyzer accepts values from 0.01 to
1.2.
Access Keys:
Softkey in the more CRT adjust menu. This is the CRT timing
adjustment for use with external monitors. Also affects the network
analyzer's internal CRT. Default setting is 31.84 µsec. This setting is
not affected by an instrument preset.
See “Using an External VGA Monitor” on page 4-87 for more
information.
Access Keys:
Softkey in the more CRT adjust menu. This is the CRT timing
adjustment for use with external monitors. Also affects the network
analyzer's internal CRT. Default setting is 16.68416 msec. This setting
is not affected by an instrument preset.
See “Using an External VGA Monitor” on page 4-87 for more
information.
Access Keys:
CAL
SYSTEM OPTIONS
SYSTEM OPTIONS
To Next Page
