ES User’s Guide 9-29
Specifications
Test Port Input
Table 9-8 Test Port Input
HP 8712ET/ES and HP 8714ET/ES Test Port Input
Description Specification Supplemental Information
Frequency Range
HP 8712ET/ES:
Narrowband 300 kHz to 1.3 GHz
Broadband 10 MHz to 1.3 GHz
HP 8714ET/ES:
Narrowband 300 kHz to 3.0 GHz
Broadband 10 MHz to 3.0 GHz
Maximum Input Level
HP 8712ET/8714ET +10 dBm at 0.5 dB compression
HP 8712ES and HP 8714ES:
Narrowband, Frequency >1 MHz +10 dBm at 0.3 dB compression
Narrowband, Frequency <1 MHz +10 dBm at 0.5 dB compression
Broadband +16 dBm at 0.55 dB compression
Damage Level
HP 8712ET/8714ET +20 dBm; ±30 VDC
HP 8712ES/8714ES +26 dBm; ±30 VDC
Broadband Flatness
HP 8712ET/ES and HP 8714ET/ES ±1 dB, characteristic
