ES User’s Guide 9-39
Specifications
General Information
Table 9-9 General Information
HP 8712ET/ES and HP 8714ET/ES General Information
Description Specification Supplemental Information
Display Range
Magnitude 200 dB (at 20 dB/div), max
Phase 1800° (at 180°/div), max
Polar 1 MUnit, max
Display Resolution
Magnitude 0.01 dB/div, min
Phase 0.1°/div, min
Polar 10 µUnit Full Scale, min
Reference Level Range
Magnitude 500 dB, max
Phase 360 °, max
Reference Level Resolution
Magnitude 0.01 dB, min
Phase 0.01°, min
Marker Resolution
Magnitude 0.001 dB, min
Phase 0.01°, min
Polar 0.01 µUnit, min; 0.01°, min
Group Delay Aperture
Minimum 20% of frequency span
Maximum frequency span ÷ (# of points − 1)
Group Delay Range
1 ÷ (2 x minimum aperture) The maximum delay is limited to
measuring no more than 180° of phase
change within the minimum aperture.
