HP BladeSystem c3000 Setup And Installation

Installing components 46
Connection Port number Connect to interconnect
bay/port
Comments
Embedded NIC
NIC 1
NIC 2
NIC 3
NIC 4
1/Port N+4
1/Port N+12
1/Port N
1/Port N+8
One single-wide Ethernet
interconnect module
Mezzanine slot 1—1x or
2x cards (4x cards are not
supported in this slot)
1x/2x port 1
1x/2x port 2
1x/2x port 3
1x/2x port 4
2/Port N
2/Port N+8
2/Port N+4
2/Port N+12
One single-wide interconnect
module
Mezzanine slot 2—1x or
2x cards
1x/2x port 1
1x/2x port 2
1x/2x port 3
1x/2x port 4
3/Port N
4/Port N
3/Port N+8
4/Port N+8
One or two single-wide
interconnect modules
Mezzanine slot 2—4x
cards
4x port 1
4x port 2
3/Port N
3/Port N+8
One double-wide interconnect
module
Mezzanine slot 3—1x or
2x cards
1x/2x port 1
1x/2x port 2
1x/2x port 3
1x/2x port 4
3/Port N+12
4/Port N+12
3/Port N+4
4/Port N+4
One or two single-wide
interconnect modules
Mezzanine slot 3—4x
cards
4x port 1
4x port 2
3/Port N+12
3/Port N+4
One double-wide interconnect
module

HP BladeSystem c3000 Specifications

General

Form Factor	6U
Maximum Number of Blade Servers	8 half-height or 4 full-height
Maximum Number of Full-Height Blades	4
Cooling Fans	6 hot-plug fans
Management	HP Onboard Administrator
Interconnect Bays	4
Fans	6 hot-plug fans
Networking Options	Ethernet, Fibre Channel, InfiniBand
Power Supplies	Up to 6 (depending on configuration)
