Configuring for Network Management Applications
LLDP (Link-Layer Discovery Protocol)
Command Page
show cdp 14-78
show cdp neighbors [< port-list > detail] 14-79
[detail < port-list >]
[no] cdp run 14-80
[no] cdp enable < port-list > 14-80
Note For details on how to use an SNMP utility to retrieve information from the
switch’s CDP Neighbors table maintained in the switch’s MIB (Management
Information Base), refer to the documentation provided with the particular
SNMP utility.
Viewing the Switch’s Current CDP Configuration. CDP is shown as
enabled/disabled both globally on the switch and on a per-port basis.
Syntax: show cdp
Lists the switch’s global and per-port CDP configuration.
The following example shows the default CDP configuration.
Figure 14-28. Example of Show CDP with the Default CDP Configuration
14-78
