Connectors, LEDs, and Switches
Table 4-16: Online Spare Memory LEDs
Item Description Indicator Status
Off DIMM is not installed.
Green DIMM is installed.
Amber Memory error has occurred on this
DIMM.
1-4
and
10-13
DIMM 1-8 status
Flashing amber Configuration error has occurred.
Off Bank is not configured as an online
spare bank.
Green Bank is configured as an online
spare bank.
5 “Online Spare” text
Flashing green Failure has occurred and online
spare bank is active.
Off Memory board is offline.
Green Memory board is online.
Flashing green Memory board is busy.
6 Memory status
Amber Memory error has occurred on this
memory board.
7 Ready to Hot Plug Off Do not remove memory board;
online spare memory does not
support hot-plug capability.
Off Memory board is not configured for
online spare memory.
Green Online spare memory is functioning
properly.
8 Online spare status
Amber Memory error has occurred and
system has failed over to the online
spare bank.
Off Memory board is not seated properly
or locking switch is not engaged;
memory board can be removed
safely.
All LEDs
Flashing amber
CAUTION: Memory board is in use;
relock it immediately.
