HP ProLiant DL580 Generation 2 - Power Button;LED assembly

Removal and Replacement Procedures
Power Button/LED assembly
To remove the power button/LED assembly:
1. Power down the server. Refer to “Power ing Down the Server” in this chapter.
2. Extend the server from the rack. Refer to “Extending the Rack from the Server” in this
chapter.
3. Remove the rear access panel. Refer to “Opening and Removing the Rear Access Panel”
in this chapter.
4. Remove the front access panel. Refer to “Re moving the Front Access Panel” in this
chapter.
5. Unplug the cable from the removable media board (1).
6. Push on the locking tab until the opposite side comes out (2).
Figure 2-32: Removing the power button/LED assembly
Reverse steps 1 through 6 to replace the power button/LED assembly.
HP ProLiant DL580 Generation 2 Server Maintenance and Service Guide 2-45
