HP ProLiant DL580 Generation 2 - Hot-Plug Mirrored Memory Leds; Memory Board Icons

Removal and Replacement Procedures
Table 2-6: Hot-Plug Mirrored Memory LEDs
Item Description Indicator Status
Off Memory board is offline.
Green Memory board is online.
Flashing green Memory board is busy.
6 Memory Status
Amber Memory error has occurred on this
memory board.
Off Memory board is not configured for
mirrored memory.
Green Hot-plug mirrored memory is functioning
properly.
9 Mirroring Status
Amber Memory error has occurred and system
has failed over to the mirrored board.
Off Do not remove memory board. 7 Ready to Hot Plug
Green Memory board can be hot-plugged.
Off DIMM is not installed.
Green DIMM is installed.
Amber Memory error has occurred on this
DIMM.
1-4 and
10-3
DIMMs 1-8 status
Flashing amber Configuration error has occurred.
All LEDs Flashing amber
CAUTION: Memory board is in use;
relock it immediately.
Table 2-7: Memory Board Icons
Description Status
Lock Memory board is locked and cannot be removed.
Unlock Memory board is unlocked, and is only hot-pluggable if the Ready to Hot Plug
LED is on.
Note: The icon at which the memory board switch is pointed indicates whether the memory board is
locked or unlocked.
HP ProLiant DL580 Generation 2 Server Maintenance and Service Guide 2-21
