Removal and Replacement Procedures
Non-Hot-Plug PCI-X Expansion Boards
To remove a non-hot-plug expansion board:
1. Power down the server. Refer to “Power ing Down the Server” in this chapter.
2. Extend the server from the rack. Refer to “Extending the Rack from the Server” in this
chapter.
3. Open the rear access panel. Refer to “Op ening and Removing the Rear Access Panel” in
this chapter.
4. Disconnect any cables connected to the expansion board.
5. Press the PCI-X retaining clip until it stays in the open position.
Figure 2-38: Pressing the PCI-X retaining clip
HP ProLiant DL580 Generation 2 Server Maintenance and Service Guide 2-51
