HP ProLiant DL580 Generation 2 - System Components Spare Parts List

Illustrated Parts Catalog
System Components Spare Parts List
Table 1-2: System Components Spare Parts List
Item Description Spare Part Number
Media Storage Devices
1 Diskette drive, 12.7 mm, multibay 267132-001
2 CD-ROM drive, 24X, multibay 228508-001
Fans
3 Fan assembly, hot-plug, 120 × 38 mm 240243-001
4 Fan assembly, hot-plug, 120 × 25 mm 240244-001
Boards
5 Memory board 231126-001
6 SCSI backplane 231128-001
7 Diagnostic display board and lightpipe 249105-001
8 Pass-through board 249106-001
9 PCI-X Hot Plug board 231127-001
9a NIC, 10/100/1000 controller* 284848-001
9b NIC, Dual PCI-X NC7170* 313586-001
10 System board 231125-001
11 Processors
a) Processor, Xeon MP, 1.4-GHz/512 KB L3
b) Processor, Xeon MP, 1.6-GHz/1 MB L3*
c) Processor, Xeon MP, 1.5 GHz/1 MB L3*
d) Processor, Xeon MP, 1.9 GHz/1 MB L3*
e) Processor, Xeon MP, 2.0 GHz/2 MB L3*
f) Processor, Xeon MP, 2.0 GHz/1-MB L3*
g) Processor, Xeon MP, 2.5 GHz/1-MB L3*
h) Processor, Xeon MP, 2.8 GHz/2-MB L3*
i) Processor, Xeon MP, 2.2 GHz/2-MB L3*
j) Processor, Xeon MP, 2.7 GHz/2-MB L3*
k.) Processor, Xeon MP, 3.0 GHz/4-MB L3*
IMPORTANT: Mixing processor speeds and cache
sizes is not supported.
272935-001
272936-001
309617-001
311277-001
309618-001
327839-001
327840-001
327841-001
352311-001
352312-001
352313-001
12 Processor power module (PPM) 266655-001
13 Power switch assembly 243670-001
* Not shown
continued
HP ProLiant DL580 Generation 2 Server Maintenance and Service Guide 1-5
