Removal and Replacement Procedures
Table 2-5: Single-Board Mirrored Memory LEDs
Item Description Indicator Status
Off Memory board is offline.
Green Memory board is online.
Flashing green Memory board is busy.
6 Memory Status
Amber Memory error has occurred on this memory
board.
Off Memory board is not configured for mirrored
memory.
Green Single-board mirrored memory is functioning
properly.
9 Mirroring Status
Amber Memory error has occurred and system has
failed over to the mirrored bank(s).
7 Ready to
Hot Plug
Off Do not remove memory board. Single-board
mirrored memory does not support hot-plug
capability.
Off DIMM is not installed.
Green DIMM is installed.
Amber Memory error has occurred on this DIMM.
1-4 and
10-13
DIMMs 1-8
status
Flashing amber Configuration error has occurred.
All LEDs Flashing amber
CAUTION: Memory board is in use; relock it
immediately.
2-20 HP ProLiant DL580 Generation 2 Server Maintenance and Service Guide
