HP ProLiant DL580 Generation 2 - Locating and Removing the Torx T-15 Tool

Removal and Replacement Procedures
Locating and Removing the Torx T-15 Tool
Many hardware procedures in the ProLiant DL580 Generation 2 server are toolless, but a few
require the removal of Torx T-15 screws that have been installed for shipping or security
reasons. A Torx T-15 tool ships with the server for the removal of these screws.
To locate and remove the Torx T-15 tool:
1. Locate the Torx T-15 tool on the back of the server. It is next to PCI-X slot 6.
2. Slide the tool out of the retaining clips.
Figure 2-1: Locating and removing the Torx T-15 tool
HP ProLiant DL580 Generation 2 Server Maintenance and Service Guide 2-5
